GPIBEE News

Announcements, firmware releases and other news around GPIBEE. RSS feed if you follow this in a reader.

GPIBee is now available in Japan / 日本で販売開始

GPIBee is now sold in Japan by Tateno Dennou (立野電脳) in Tokyo, with a Japanese catalog and a launch price for academic and other customers. The quick start guide, the manual and a product overview are on this site in Japanese as well.

ResellersJapanAvailability
Read more

Firmware V1.7, with updates over the network and a password for the web interface

V1.7.2611152105 can update itself over Ethernet or USB networking, so you no longer need the USB bootloader and the mass storage device it presents. That matters on company PCs where USB storage is blocked by policy. The web interface can also be password protected now, the ++ protocol gained eleven commands plus parallel poll configuration, and idle HTTP connections are closed after 45 seconds so discovery services stop piling up. There is still no update check that calls a server, because the adapter never phones home.

FirmwareReleaseV1.7++protocolWeb interface
Read more

Latency first: how fast is GPIBee, really?

Most GPIB programs send short commands, not megabytes, so the time one query takes decides how fast a setup feels. Measured latency and throughput for every GPIBee interface mode against a popular high-end USB adapter, plus histograms from more than 11 million timed transfers, and what the five one-second outliers say about choosing a timeout.

PerformanceLatencyBenchmarkTesting
Read more

Eye mask testing on an HP 54845A, and firmware V1.6.2610222113

Four new benches for the HP 54845A Infiniium are on the Benches page, one of them a mask test that sets the scope up and loads an eye mask for USB full speed, USB high speed, 10BASE-T or 100BASE-TX. Five mask files come with it. Firmware V1.6.2610222113 addresses a round of issues in the ++ protocol, and VisaMCP now carries a knowledge base of more than 1200 instruments.

BenchesFirmwareReleaseMask test++protocolVisaMCP
Read more

Firmware V1.6.2610181527, and an AI experiment called VisaMCP

Firmware V1.6.2610181527 is out, with a VXI-11 fix for the internal SCPI device and a round of Benches changes: a clearer second-bench selector, a warning before an import throws away unsaved work, readings that pick a sensible font size, better error messages, and a REST API that keeps its connection open. The PyVISA Code Generator gained an optional instrument picker with termination settings from over a thousand manuals. And VisaMCP is an experiment that lets an AI assistant talk to instruments through any VISA.

FirmwareReleaseBenchesToolsVisaMCP
Read more

Three more benches, and one that did not make it

Three ready-made benches joined the Benches page: a Philips PM5191 function generator, an HP 5335A universal counter and a Marconi 2019A signal generator. The PM5191 was contributed by beta tester Dethmer Kupers. A Gould oscilloscope was supposed to be the fourth.

BenchesExamples
Read more

Four new tutorials, and parallel poll for Linux GPIB

Four new tutorials are online: Excel VBA, C with Code::Blocks, Lazarus / Free Pascal / Delphi, and GNU Octave on Linux. Each comes with a ready-made project or script to download. Separately, the GPIBee driver in linux-gpib gained parallel poll and a settable T1 delay.

TutorialsLinux GPIBExamples
Read more

GPIBee is now available across Europe, from Batronix

Batronix in northern Germany now carries GPIBee and ships across Europe, Switzerland and the United Kingdom included. Buying inside the EU no longer means an import from the United States. There is a nice coincidence in it as well.

ResellersEuropeAvailability
Read more

Firmware V1.6.2609061128: getting humbled, and back to being boring

A user reported that his GPIBee stopped responding after about a day of continuous operation. This build fixes the slow memory leak behind it, and firmware now runs here for weeks before it is released. Also in this release, unrelated to that: screenshot downloads in Benches are about ten times faster, and download buttons show progress.

FirmwareReleaseStabilitySSDP
Read more

Your GPIB instrument just got a web interface

GPIBee V1.6 introduces Benches: build a browser front panel for any GPIB instrument in minutes, without writing software. Switch a supply on from the kitchen table, read a meter from your phone, and give a 1985 instrument the web interface it never had.

BenchesV1.6Web interfaceRemote controlNo-code
Read more

Firmware V1.5.2608231522: a step up in VXI-11 compliance

A new firmware build is available. The headline is VXI-11: a conformance test suite written for this project covers 104 rules of the specification, and all of them now pass. Also in this release, a working abort channel, the VXI-11.2 low-level bus commands, and fixes to link locking, instance names and fragmented RPC records.

FirmwareReleaseVXI-11
Read more

How GPIBee is tested

A look at how GPIBee's firmware is verified: a GPIB bus spanning five decades of instruments, regression suites for USBTMC and VXI-11, and a VXI-11 standards compliance suite written from scratch because none existed. Its first run passed 69.4% of its checks. Here is what it found and how that was fixed.

TestingQualityVXI-11USBTMCFirmware
Read more

Quick take: GPIBee over a raw TCP socket

Someone asked on YouTube whether GPIBee can be used like the raw TCP socket that many instruments expose on port 5025. It can. Here is the short answer, and the one thing that is different because GPIBee is a gateway.

Quick takeProtocols++protocol
Read more
