How GPIBee is tested

🟢 122 check(s) passed · ⚪ 1 skipped

🟢 Every check that ran passed.

Pass rate 100.0% — 122 of 122 applicable checks (🔴 0.0% failed, 🟡 0.0% warned; 1 skipped checks excluded).

By suite

Passing

🟢 122 of 123 checks passed (99.2%). Ids below are shown without the common VXI11-TS- prefix.

• Abort channel (11): EXT ABT-001, EXT ABT-005, REC B.2.1, RULE B.2.5, RULE B.2.8, RULE B.6.107, RULE B.6.108, RULE B.6.109, RULE B.6.12, RULE B.6.2-a, RULE B.6.81
• cmd (18): EXT CMD-001, EXT CMD-002, RULE B.1.3, RULE B.4, RULE B.4.10, RULE B.4.12, RULE B.4.17, RULE B.5, RULE B.5.1, RULE B.5.10, RULE B.5.11, RULE B.5.2, RULE B.5.3, RULE B.5.4, RULE B.5.5, RULE B.5.6, RULE B.5.7, RULE B.5.8
• gen (6): EXT GEN-001, RULE B.6.39, RULE B.6.47, RULE B.6.55, RULE B.6.63, RULE B.6.98
• Interrupt channel (16): EXT INT-005, RULE B.2.10, RULE B.4.5-b, RULE B.6.111, RULE B.6.82, RULE B.6.83, RULE B.6.85, RULE B.6.86, RULE B.6.87, RULE B.6.88, RULE B.6.89, RULE B.6.90, RULE B.6.92, RULE B.6.93-a, RULE B.6.93-b, RULE B.6.95
• Read / write (14): EXT IO-005, EXT IO-010, EXT IO-011, EXT IO-012, OBS B.6.6, RULE B.6.13, RULE B.6.16, RULE B.6.23-a, RULE B.6.23-b, RULE B.6.23-c, RULE B.6.23-d, RULE B.6.27, RULE B.6.3-d, RULE B.6.31
• Locking (13): EXT LCK-007, RULE B.4.3, RULE B.6.17, RULE B.6.18, RULE B.6.71, RULE B.6.72, RULE B.6.74-a, RULE B.6.74-b, RULE B.6.75, RULE B.6.76, RULE B.6.80-a, RULE B.6.80-b, RULE B.6.9
• Link lifecycle (16): EXT LNK-003, EXT LNK-006, EXT LNK-007, EXT LNK-011, REC B.6.1, RULE B.2.7, RULE B.4.5-a, RULE B.6.10-a, RULE B.6.10-b, RULE B.6.15, RULE B.6.3-a, RULE B.6.3-b, RULE B.6.3-c, RULE B.6.4, RULE B.6.6, RULE B.6.7
• Port mapper (9): EXT PM-003, EXT PM-004, EXT PM-005, EXT PM-008, EXT PM-009, RULE B.1.4, RULE B.2.1-a, RULE B.2.1-b, RULE B.6.1-a
• Robustness (6): EXT ROB-003, EXT ROB-005, EXT ROB-006, REC B.4.2, RULE B.4.5-c, RULE B.6.5
• RPC layer (13): EXT RPC-004, EXT RPC-005, EXT RPC-006, EXT RPC-007, EXT RPC-008, EXT RPC-009, EXT RPC-011, RULE B.1.5, RULE B.2.2, RULE B.2.3, RULE B.6.1-b, RULE B.6.2-b, RULE C.1

Coverage of the standards

137 of the 187 catalogued statements are exercised by this run, 50 are not checkable from a client on the network, 0 are not covered yet.

VXI-11 TCP/IP Instrument Protocol Specification, Revision 1.0

VXI-11.2 TCP/IP-IEEE 488.1 Interface Specification, Draft 0.3

Not checkable from the network

• VXI-11 RULE B.1.1 — Hosts support Ethernet/802.3 and 10BASE-T with an RJ-45 connector.
  physical layer -- inspect the hardware, not the protocol
• VXI-11 RULE B.4.1 — A server supports links to every device reachable by any other server in the host.
  needs two servers in the same host and knowledge of its device list
• VXI-11 RULE B.4.4 — The client provides a local timeout for unresponsive servers.
  a rule for the client, which this suite implements itself
• VXI-11 RULE B.6.8 — create_link has no effect on the state of any device.
  requires observing device state through a second, independent path
• VXI-11 RULE B.6.11 — destroy_link has no effect on the state of any device.
  requires observing device state through a second, independent path
• VXI-11 RULE B.6.19 — device_write returns error 15 if the whole transfer has not completed within io_timeout.
  needs a device that stalls a write; only device_read can be stalled reliably from the network side (RULE B.6.27)
• VXI-11 RULE B.6.20 — device_write returns error 23 if device_abort is called during it.
  these operations finish too quickly to be aborted deterministically; the abort path is checked on device_read and device_lock (RULE B.6.107, RULE B.6.76)
• VXI-11 RULE B.6.21 — device_write returns the bytes transferred in size even when it ends in a timeout or an abort.
  requires a write that times out or is aborted mid-transfer
• VXI-11 RULE B.6.22 — device_write returns error 17 on a device specific I/O error.
  needs an induced device I/O error (pull the bus cable)
• VXI-11 RULE B.6.28 — device_read returns error 17 on a device specific I/O error.
  needs an induced device I/O error
• VXI-11 RULE B.6.36 — device_readstb returns error 15 if not complete within io_timeout.
  needs an operation that stalls; see RULE B.6.27
• VXI-11 RULE B.6.37 — device_readstb returns error 17 on a device specific I/O error.
  needs an induced device I/O error
• VXI-11 RULE B.6.38 — device_readstb returns error 23 when aborted.
  see RULE B.6.20
• VXI-11 RULE B.6.44 — device_trigger returns error 15 if not complete within io_timeout.
  needs an operation that stalls; see RULE B.6.27
• VXI-11 RULE B.6.45 — device_trigger returns error 17 on a device specific I/O error.
  needs an induced device I/O error
• VXI-11 RULE B.6.46 — device_trigger returns error 23 when aborted.
  see RULE B.6.20
• VXI-11 RULE B.6.52 — device_clear returns error 15 if not complete within io_timeout.
  needs an operation that stalls; see RULE B.6.27
• VXI-11 RULE B.6.53 — device_clear returns error 17 on a device specific I/O error.
  needs an induced device I/O error
• VXI-11 RULE B.6.54 — device_clear returns error 23 when aborted.
  see RULE B.6.20
• VXI-11 RULE B.6.60 — device_remote returns error 15 if not complete within io_timeout.
  needs an operation that stalls; see RULE B.6.27
• VXI-11 RULE B.6.61 — device_remote returns error 17 on a device specific I/O error.
  needs an induced device I/O error
• VXI-11 RULE B.6.62 — device_remote returns error 23 when aborted.
  see RULE B.6.20
• VXI-11 RULE B.6.68 — device_local returns error 15 if not complete within io_timeout.
  needs an operation that stalls; see RULE B.6.27
• VXI-11 RULE B.6.69 — device_local returns error 17 on a device specific I/O error.
  needs an induced device I/O error
• VXI-11 RULE B.6.70 — device_local returns error 23 when aborted.
  see RULE B.6.20
• VXI-11 RULE B.6.96 — device_docmd executes the operation of cmd, byte-swapping as needed, returns data_out and error 0.
  needs a cmd value the server supports; those are defined by the companion documents (VXI-11.1 to VXI-11.3)
• VXI-11 RULE B.6.103 — device_docmd returns error 15 if cmd cannot complete within io_timeout.
  needs a supported cmd that stalls; see RULE B.6.27
• VXI-11 RULE B.6.104 — device_docmd returns error 17 on a device specific I/O error.
  needs an induced device I/O error
• VXI-11 RULE B.6.105 — device_docmd returns error 23 when aborted.
  see RULE B.6.20
• VXI-11.2 RULE B.1 — The interface device complies with IEEE 488.1 and with the controller requirements of IEEE 488.2 section 15.
  IEEE 488.1 / 488.2 controller conformance -- a bus analyser question, not a network one
• VXI-11.2 RULE B.2 — The interface device contains a Talker subset T5-T8 and a Listener subset L3 or L4.
  Talker and Listener subsets are visible only on the bus
• VXI-11.2 RULE B.2.2 — Ethernet/802.3 and 802.3/10BASE-T with an RJ-45 connector are supported.
  physical layer -- inspect the hardware
• VXI-11.2 RULE B.3.1 — create_link and destroy_link are implemented entirely within the interface device.
  an internal structure requirement; its effects are covered by the VXI-11 link rules
• VXI-11.2 RULE B.3.2 — create_intr_chan and destroy_intr_chan are implemented entirely within the interface device.
  internal structure; effects covered by the VXI-11 interrupt channel rules
• VXI-11.2 RULE B.3.3 — device_lock and device_unlock are implemented entirely within the interface device.
  internal structure; effects covered by the VXI-11 locking rules
• VXI-11.2 RULE B.3.4 — device_abort is implemented entirely within the interface device and aborts active operations on the link.
  internal structure; effects covered by VXI-11 RULE B.6.107
• VXI-11.2 RULE B.4.1 — device_write on a device link uses the SEND control sequence with the link's listen address; END on the last byte when the end flag is set.
  the SEND control sequence is only observable with a bus analyser
• VXI-11.2 RULE B.4.2 — device_write on an interface link uses SEND DATA BYTES.
  bus-level sequence; needs an analyser
• VXI-11.2 RULE B.4.3 — device_read on a device link uses the RECEIVE control sequence with the link's talk address.
  bus-level sequence; needs an analyser
• VXI-11.2 RULE B.4.4 — device_read on an interface link uses RECEIVE RESPONSE MESSAGE.
  bus-level sequence; needs an analyser
• VXI-11.2 RULE B.4.5 — device_clear on a device link executes DEVICE CLEAR for the selected device.
  bus-level sequence; needs an analyser
• VXI-11.2 RULE B.4.6 — device_clear on an interface link executes DEVICE CLEAR for all devices.
  bus-level sequence; needs an analyser
• VXI-11.2 RULE B.4.7 — device_trigger on a device link executes TRIGGER for the selected device.
  bus-level sequence; needs an analyser
• VXI-11.2 RULE B.4.8 — device_trigger on an interface link executes TRIGGER for all addressed devices.
  bus-level sequence; needs an analyser
• VXI-11.2 RULE B.4.9 — device_remote on a device link executes SET RWLS.
  bus-level sequence; needs an analyser
• VXI-11.2 RULE B.4.11 — device_local on a device link executes ENABLE LOCAL CONTROLS for the selected device.
  bus-level sequence; needs an analyser
• VXI-11.2 RULE B.4.13 — device_intr_srq is sent when SRQ goes false to true and the channel exists with service requests enabled.
  needs a controlled SRQ transition on the bus; the delivery path is covered by VXI-11 RULE B.6.111
• VXI-11.2 RULE B.4.14 — device_intr_srq is sent when service requests are enabled while SRQ is already true.
  needs SRQ already asserted before enabling; same path as RULE B.4.13
• VXI-11.2 RULE B.4.15 — device_intr_srq is not sent under any other circumstances.
  proving a negative over all circumstances is not possible from the network side
• VXI-11.2 RULE B.4.16 — device_readstb on a device link executes READ STATUS BYTE and returns the status byte with the RQS message.
  the READ STATUS BYTE sequence is only observable with a bus analyser; the result is checked by VXI-11 RULE B.6.31

Summary

Details

🟢 VXI11.2-RULE-B.1.3 — A device string with no address links to the interface

Verifies:

• VXI-11.2 RULE B.1.3 A device string containing only the interface name is a link to the interface.
• VXI-11.2 RULE B.1.2 The interface name gpib0 is the first or only IEEE 488.1 interface; further interfaces are gpibN.
• VXI-11.2 RULE B.1.1 The device string has the form [,[,]].

What is checked: 'gpib0' on its own must open a link to the interface rather than to a device; device_docmd needs such a link

Observed: interface link opened on 'gpib0'

interface link 0 on 'gpib0'

↑ back to summary

🟢 VXI11-RULE-B.1.4 — Portmapper answers on TCP/111

Verifies:

• VXI-11 RULE B.1.4 A host acting as a network instrument server supports a port mapper.

What is checked: the server must register with the port mapper

↑ back to summary

🟢 VXI11-RULE-B.1.5 — Every procedure defined by the standard is implemented

Verifies:

• VXI-11 RULE B.1.5 Hosts implement all the messages and data types of B.5 and B.6.
• VXI-11 RULE B.6.1 The program and version numbers of Table B.3 are used: core 395183/1, abort 395184/1, interrupt 395185/1.
• VXI-11 RULE B.1.2 Hosts support the Internet Protocol Suite; TCP is the transport layer.
• VXI-11.2 RULE B.2.1 The interface device supports the network instrument protocol and executes all of its RPCs.

What is checked: all 15 core channel procedures and device_abort on the async channel must exist; a missing one shows up as PROC_UNAVAIL long before any device-level error code does

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
create_link -> MSG_ACCEPTED/SUCCESS
device_write -> MSG_ACCEPTED/SUCCESS
device_read -> MSG_ACCEPTED/SUCCESS
device_readstb -> MSG_ACCEPTED/SUCCESS
device_trigger -> MSG_ACCEPTED/SUCCESS
device_clear -> MSG_ACCEPTED/SUCCESS
device_remote -> MSG_ACCEPTED/SUCCESS
device_local -> MSG_ACCEPTED/SUCCESS
device_lock -> MSG_ACCEPTED/SUCCESS
device_unlock -> MSG_ACCEPTED/SUCCESS
device_enable_srq -> MSG_ACCEPTED/SUCCESS
device_docmd -> MSG_ACCEPTED/SUCCESS
destroy_intr_chan -> MSG_ACCEPTED/SUCCESS
create_intr_chan -> MSG_ACCEPTED/SUCCESS
destroy_link -> MSG_ACCEPTED/SUCCESS

↑ back to summary

🟢 VXI11-RULE-B.2.1-a — The advertised core port accepts TCP connections

Verifies:

• VXI-11 RULE B.2.1 The server implements all three channels, established by the sequences of B.2.4 and B.2.5.

What is checked: the registered port must be the live core channel

↑ back to summary

🟢 VXI11-RULE-B.2.1-b — The advertised abort port accepts TCP connections

Verifies:

• VXI-11 RULE B.2.1 The server implements all three channels, established by the sequences of B.2.4 and B.2.5.

What is checked: VXI-11 B.2

↑ back to summary

🟢 VXI11-RULE-B.2.2 — Two calls pipelined on one connection are both answered

Verifies:

• VXI-11 RULE B.2.2 Core channel RPCs are processed in the order received, and the reply is not sent until the action is complete.
• VXI-11.2 RULE B.3 The RPC reply is not sent until the associated action is complete.

What is checked: a client may have several calls outstanding on one connection

xids answered: ['0x4100001d', '0x4100001e']

↑ back to summary

🟢 VXI11-RULE-B.2.3 — An unknown program number gives PROG_UNAVAIL

Verifies:

• VXI-11 RULE B.2.3 Other protocols carried on the core channel under different program numbers do not interfere with the instrument protocol.

What is checked: MSG_ACCEPTED with PROG_UNAVAIL for programs the server does not implement

prog 0x0607FE -> MSG_ACCEPTED/PROG_UNAVAIL

↑ back to summary

🟢 VXI11-RULE-B.2.5 — The abort channel rejects unknown procedures

Verifies:

• VXI-11 RULE B.2.5 The abort channel carries only the device_abort RPC.

What is checked: an unimplemented procedure gives PROC_UNAVAIL

abort channel proc 42 -> MSG_ACCEPTED/PROC_UNAVAIL

↑ back to summary

🟢 VXI11-RULE-B.2.7 — Every create_link on one core channel returns the same abort port

Verifies:

• VXI-11 RULE B.2.7 The same abort port number is returned in every create_link reply sent on one core channel.

What is checked: the abort port identifies the connection's abort channel, not the individual link, so it must not change between create_link replies

abort ports returned: [34568, 34568, 34568]

↑ back to summary

🟢 VXI11-RULE-B.2.8 — The core channel works when no abort channel is ever established

Verifies:

• VXI-11 RULE B.2.8 The server accepts and processes core channel RPCs even if an abort channel is never established.

What is checked: the abort channel is optional for the client; a connection that never opens one must be served normally

↑ back to summary

🟢 VXI11-RULE-B.2.10 — The interrupt channel is closed when destroy_intr_chan is called

Verifies:

• VXI-11 RULE B.2.10 destroy_intr_chan makes the server destroy its RPC client and tear the interrupt channel down.

What is checked: the TCP connection to the client must be torn down cleanly

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
interrupt listener on 0.0.0.0:58834
create_intr_chan -> 192.168.3.3:58834

↑ back to summary

🟢 VXI11.2-RULE-B.4 — At least 14 concurrent links per server

Verifies:

• VXI-11.2 RULE B.4 At least 14 concurrent links per network instrument server are supported.
• VXI-11.2 REC B.2 Link and server counts should follow available resources, not arbitrary limits.

What is checked: an IEEE 488.1 interface device supports at least 14 links on one network instrument server

14 concurrent links on one connection

↑ back to summary

🟢 VXI11-RULE-B.4.3 — lock_timeout=0 with waitlock does not block

Verifies:

• VXI-11 RULE B.4.3 With a non-zero lock_timeout the server waits at least that long for a lock; with lock_timeout zero it does not wait at all and returns an error immediately.

What is checked: lock_timeout 0 means do not wait at all

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
waitlock with lock_timeout=0 -> 11 (device locked by another link) after 47 ms

↑ back to summary

🟢 VXI11-RULE-B.4.5-a — Closing the core connection releases the link's resources

Verifies:

• VXI-11 RULE B.4.5 When the core channel is reset or closed, the server releases all resources of every link on that connection -- locks, abort channel and interrupt channel included.
• VXI-11 RULE B.6.77 Locks are tied to the core connection; a broken connection releases all of that connection's locks.

What is checked: an aborted TCP connection must not leak links or locks

opened and locked lid 0, then dropping the TCP connection
reclaimed after 0.0s

↑ back to summary

🟢 VXI11-RULE-B.4.5-b — The interrupt channel is torn down when the core connection drops

Verifies:

• VXI-11 RULE B.4.5 When the core channel is reset or closed, the server releases all resources of every link on that connection -- locks, abort channel and interrupt channel included.

What is checked: closing the core channel ends the session, including its interrupt channel

interrupt listener on 0.0.0.0:58874
create_intr_chan -> 192.168.3.3:58874

↑ back to summary

🟢 VXI11-RULE-B.4.5-c — Links are reclaimed when clients disappear without destroy_link

Verifies:

• VXI-11 RULE B.4.5 When the core channel is reset or closed, the server releases all resources of every link on that connection -- locks, abort channel and interrupt channel included.
• VXI-11 REC B.4.3 The server should detect a downed network or crashed client and clean up as for a closed connection.

What is checked: a server must not leak link resources when a client dies

25 connect/create_link/kill cycles survived

↑ back to summary

🟢 VXI11.2-RULE-B.4.10 — device_remote on an interface link returns error 8

Verifies:

• VXI-11.2 RULE B.4.10 device_remote on an interface link returns error 8.

What is checked: remote state applies to a device, not to the interface

interface link 0 on 'gpib0'
device_remote on the interface link -> 8 (operation not supported)

↑ back to summary

🟢 VXI11.2-RULE-B.4.12 — device_local on an interface link returns error 8

Verifies:

• VXI-11.2 RULE B.4.12 device_local on an interface link returns error 8.

What is checked: local state applies to a device, not to the interface

interface link 0 on 'gpib0'
device_local on the interface link -> 8 (operation not supported)

↑ back to summary

🟢 VXI11.2-RULE-B.4.17 — device_readstb on an interface link returns error 8

Verifies:

• VXI-11.2 RULE B.4.17 device_readstb on an interface link returns error 8.

What is checked: an interface has no status byte to read

interface link 0 on 'gpib0'
device_readstb on the interface link -> 8 (operation not supported)

↑ back to summary

🟢 VXI11.2-RULE-B.5 — REN is true after power-on

Verifies:

• VXI-11.2 RULE B.5 After power-on the interface device sets REN true.

What is checked: the interface device sets REN true after power-on; this reads it back through Bus Status, so it only holds if nothing has cleared REN since

interface link 0 on 'gpib0'
REMOTE = 1

↑ back to summary

🟢 VXI11.2-RULE-B.5.1 — Only the cmd values of Table B.1 are accepted

Verifies:

• VXI-11.2 RULE B.5.1 Only the cmd values of Table B.1 are supported; any other cmd returns immediately with error 8.

What is checked: any cmd outside Table B.1 returns immediately with error 8, including values inside the reserved 0x020000-0x02FFFF range

interface link 0 on 'gpib0'
cmd 0x000000 -> 8 (operation not supported)
cmd 0x000001 -> 8 (operation not supported)
cmd 0x020005 -> 8 (operation not supported)
cmd 0x0200FF -> 8 (operation not supported)
cmd 0x02FFFF -> 8 (operation not supported)
cmd 0x7FFFFFFF -> 8 (operation not supported)

↑ back to summary

🟢 VXI11.2-RULE-B.5.2 — device_docmd on a device link returns error 8

Verifies:

• VXI-11.2 RULE B.5.2 device_docmd on a link associated with a device performs no action and returns error 8.

What is checked: a link associated with a device performs no action for any cmd and returns 'operation not supported'

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
Bus Status on the device link 'gpib0,4' -> 8 (operation not supported)

↑ back to summary

🟢 VXI11.2-RULE-B.5.3 — A wrong data_in length or datasize gives error 5

Verifies:

• VXI-11.2 RULE B.5.3 A data_in_len or datasize conflicting with Table B.1 gives error 5 and no action; datasize X accepts any value.

What is checked: Table B.1 fixes data_in_len and datasize per cmd; a mismatch is a parameter error and the operation must not be performed

interface link 0 on 'gpib0'
Bus Status, datasize 1 -> 5 (parameter error)
Bus Status, data_in 1 byte -> 5 (parameter error)
Bus Status, data_in 4 bytes -> 5 (parameter error)
Bus Status, datasize 4 -> 5 (parameter error)

↑ back to summary

🟢 VXI11.2-RULE-B.5.4 — data_in and data_out are byte-swapped when asked

Verifies:

• VXI-11.2 RULE B.5.4 data_in and data_out hold unsigned integers of datasize bytes.
• VXI-11 RULE B.6.99 The server byte-swaps data_in and data_out when its architecture differs from the client's, per network_order.
• VXI-11 RULE B.6.100 Byte swapping follows datasize: 1 none, 2 word, 4 longword, 8 eight-byte boundaries.

What is checked: with network_order false the client is little-endian, so the server swaps data_in and data_out on datasize boundaries. Bus Status uses datasize 2, which makes the swap observable

interface link 0 on 'gpib0'
network order: data_in=b'\x00\x08' data_out=b'\x00\x00' (address 0)
little endian: data_in=b'\x08\x00' -> 0 (no error) data_out=b'\x00\x00'

↑ back to summary

🟢 VXI11.2-RULE-B.5.5 — Send Command transfers command bytes and echoes them

Verifies:

• VXI-11.2 RULE B.5.5 Send Command (0x020000) executes SEND COMMAND with the bytes in data_in and returns them unchanged in data_out.

What is checked: the bytes in data_in are sent with the SEND COMMAND sequence and returned unchanged. UNL (0x3F) and UNT (0x5F) are used here: they unaddress the bus, which is how every addressed sequence starts anyway

interface link 0 on 'gpib0'
data_out = b'?_'

↑ back to summary

🟢 VXI11.2-RULE-B.5.6 — Bus Status returns two bytes for every subcode

Verifies:

• VXI-11.2 RULE B.5.6 Bus Status (0x020001) returns a two-byte data_out whose value depends on the subcode in data_in per Table B.2.
• VXI-11.2 RULE B.5.4 data_in and data_out hold unsigned integers of datasize bytes.

What is checked: each subcode of Table B.2 returns a two-byte value: 0 or 1 for the line and state queries, 0 to 30 for the bus address

Observed: address 0, REN 1, SRQ 0

interface link 0 on 'gpib0'
REMOTE                 = 1
SRQ                    = 0
NDAC                   = 1
SYSTEM CONTROLLER      = 1
CONTROLLER-IN-CHARGE   = 1
TALKER                 = 0
LISTENER               = 0
BUS ADDRESS            = 0

↑ back to summary

🟢 VXI11.2-RULE-B.5.7 — ATN Control sets and clears ATN

Verifies:

• VXI-11.2 RULE B.5.7 ATN Control (0x020002) sets ATN true for a non-zero data_in and false for zero; data_out repeats data_in.

What is checked: a non-zero data_in asserts ATN, zero releases it, and data_out repeats data_in. Holding ATN interferes with data transfers, so this check restores ATN false when it is done

interface link 0 on 'gpib0'
ATN Control(1) -> 0 (no error) data_out=b'\x00\x01'
ATN Control(0) -> 0 (no error) data_out=b'\x00\x00'

↑ back to summary

🟢 VXI11.2-RULE-B.5.8 — REN Control sets REN and echoes data_in

Verifies:

• VXI-11.2 RULE B.5.8 REN Control (0x020003) sets the sre message true for a non-zero data_in and false for zero; data_out repeats data_in.

What is checked: a non-zero data_in sets the sre message true, zero sets it false, and data_out repeats data_in. This check only ever sets REN true, which is the post power-on state, so it cannot leave instruments stuck in local

interface link 0 on 'gpib0'
data_out = b'\x00\x01'

↑ back to summary

⚪ VXI11.2-RULE-B.5.9 — Pass Control hands control to the given address

Verifies:

• VXI-11.2 RULE B.5.9 Pass Control (0x020004) executes PASS CONTROL with the talk address data_in | 0x80; data_out repeats data_in.

What is checked: PASS CONTROL is executed with the talk address data_in | 0x80. This leaves the gateway no longer controller-in-charge, so it only runs with DOCMD_ALLOW_BUS_CONTROL and a target that can take control

Observed: no PASS_CONTROL_ADDRESS configured; passing control to a device that cannot take it leaves the bus without a controller

↑ back to summary

🟢 VXI11.2-RULE-B.5.10 — Bus Address accepts 0-30 and rejects anything else

Verifies:

• VXI-11.2 RULE B.5.10 Bus Address (0x02000A) sets the interface address when data_in is 0 to 30, otherwise returns error 5; data_out repeats data_in.

What is checked: an address outside 0 to 30 is a parameter error; a valid one is applied and echoed. This check writes back the address the gateway already has, so it changes nothing

interface link 0 on 'gpib0'
current bus address = 0
Bus Address(31) -> 5 (parameter error)
Bus Address(255) -> 5 (parameter error)
Bus Address(1000) -> 5 (parameter error)

↑ back to summary

🟢 VXI11.2-RULE-B.5.11 — IFC Control sends IFC and returns no data

Verifies:

• VXI-11.2 RULE B.5.11 IFC Control (0x020010) executes SEND IFC and returns an empty data_out.

What is checked: SEND IFC is executed and data_out comes back empty. IFC reinitialises the bus and unaddresses every device

interface link 0 on 'gpib0'
data_out = b''

↑ back to summary

🟢 VXI11-RULE-B.6.1-a — DEVICE_CORE (0x0607AF) v1 is registered

Verifies:

• VXI-11 RULE B.6.1 The program and version numbers of Table B.3 are used: core 395183/1, abort 395184/1, interrupt 395185/1.

What is checked: the core channel program must be resolvable via GETPORT

core channel on port 1024

↑ back to summary

🟢 VXI11-RULE-B.6.1-b — A wrong program version gives PROG_MISMATCH with a version range

Verifies:

• VXI-11 RULE B.6.1 The program and version numbers of Table B.3 are used: core 395183/1, abort 395184/1, interrupt 395185/1.

What is checked: PROG_MISMATCH must carry the supported low/high versions

DEVICE_CORE version 7 -> MSG_ACCEPTED/PROG_MISMATCH (low=1 high=1)

↑ back to summary

🟢 VXI11-RULE-B.6.2-a — The core channel does not implement the abort procedure

Verifies:

• VXI-11 RULE B.6.2 Only the defined procedure numbers are used with those programs; all others are reserved.

What is checked: device_abort lives on the async channel only

Observed: core channel proc 1 -> MSG_ACCEPTED/PROC_UNAVAIL

proc 1 on the core channel -> MSG_ACCEPTED/PROC_UNAVAIL

↑ back to summary

🟢 VXI11-RULE-B.6.2-b — An unimplemented procedure gives PROC_UNAVAIL

Verifies:

• VXI-11 RULE B.6.2 Only the defined procedure numbers are used with those programs; all others are reserved.

What is checked: PROC_UNAVAIL for procedures outside the program's set

core proc 21 -> MSG_ACCEPTED/PROC_UNAVAIL
core proc 24 -> MSG_ACCEPTED/PROC_UNAVAIL
core proc 99 -> MSG_ACCEPTED/PROC_UNAVAIL

↑ back to summary

🟢 VXI11-RULE-B.6.3-a — create_link on the configured device succeeds

Verifies:

• VXI-11 RULE B.6.3 create_link locks the device if lockDevice is set, returns a lid unique among active links, a maxRecvSize of at least 1024, the abort port, and error 0.
• VXI-11.2 RULE B.1.4 A device string with an address is a link to the device at that address.

What is checked: create_link returns error 0 plus lid, abortPort and maxRecvSize

lid=0 abortPort=34568 maxRecvSize=1024

↑ back to summary

🟢 VXI11-RULE-B.6.3-b — maxRecvSize is at least 1024 bytes

Verifies:

• VXI-11 RULE B.6.3 create_link locks the device if lockDevice is set, returns a lid unique among active links, a maxRecvSize of at least 1024, the abort port, and error 0.

What is checked: create_link returns in maxRecvSize the largest data parameter the server accepts in device_write, and that value SHALL be at least 1024

Observed: maxRecvSize = 1024

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)

↑ back to summary

🟢 VXI11-RULE-B.6.3-c — Link identifiers are unique across connections

Verifies:

• VXI-11 RULE B.6.3 create_link locks the device if lockDevice is set, returns a lid unique among active links, a maxRecvSize of at least 1024, the abort port, and error 0.

What is checked: a lid identifies exactly one link

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
link 16777216 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
link 33554432 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
lids: [0, 16777216, 33554432]

↑ back to summary

🟢 VXI11-RULE-B.6.3-d — A write of exactly maxRecvSize bytes is accepted

Verifies:

• VXI-11 RULE B.6.3 create_link locks the device if lockDevice is set, returns a lid unique among active links, a maxRecvSize of at least 1024, the abort port, and error 0.
• VXI-11 OBS B.6.5 A client sending more than maxRecvSize bytes splits the transfer over several device_write calls.

What is checked: the server must accept a data parameter up to maxRecvSize

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
writing 1024 bytes (maxRecvSize=1024)

↑ back to summary

🟢 VXI11-RULE-B.6.4 — clientId is echoed back or ignored, never rejected

Verifies:

• VXI-11 RULE B.6.4 The server does not alter its function based on clientId.

What is checked: clientId is advisory; unusual values must not break link creation

clientId=0 -> 0 (no error)
clientId=-1 -> 0 (no error)
clientId=2147483647 -> 0 (no error)

↑ back to summary

🟢 VXI11-RULE-B.6.5 — Running out of links is reported as error 9, not a crash

Verifies:

• VXI-11 RULE B.6.5 create_link with no link available terminates with error 9.

What is checked: 'out of resources' is the defined answer when no link can be created

opened 16 links before 9 (out of resources)

↑ back to summary

🟢 VXI11-RULE-B.6.6 — create_link with lockDevice=false ignores an existing lock

Verifies:

• VXI-11 RULE B.6.6 create_link ignores locks when lockDevice is false.

What is checked: the operation of create_link ignores locks if lockDevice is false, so a link may always be created on a locked device as long as it does not ask for the lock itself

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
link 0 holds the lock
create_link(lockDevice=false) on the locked device -> 0 (no error)

↑ back to summary

🟢 VXI11-RULE-B.6.7 — create_link with lockDevice=true acquires the lock

Verifies:

• VXI-11 RULE B.6.7 With lockDevice true and the lock still held after lock_timeout, create_link creates no link and returns error 11.

What is checked: lockDevice locks the device as part of link creation

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
second locking create_link -> 11 (device locked by another link)

↑ back to summary

🟢 VXI11-RULE-B.6.9 — destroy_link releases the lock the link held

Verifies:

• VXI-11 RULE B.6.9 destroy_link deactivates the lid, frees the lock this link holds, disables this link's interrupts, and returns error 0.

What is checked: destroying a link frees any lock it holds

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
link B lock after A was destroyed -> 0 (no error)

↑ back to summary

🟢 VXI11-RULE-B.6.10-a — destroy_link with an unknown link identifier gives error 4

Verifies:

• VXI-11 RULE B.6.10 destroy_link with a lid matching no active link returns error 4.

What is checked: destroy_link on an unknown lid returns 'invalid link identifier'

↑ back to summary

🟢 VXI11-RULE-B.6.10-b — destroy_link twice on the same link gives error 4

Verifies:

• VXI-11 RULE B.6.10 destroy_link with a lid matching no active link returns error 4.
• VXI-11 RULE B.6.9 destroy_link deactivates the lid, frees the lock this link holds, disables this link's interrupts, and returns error 0.

What is checked: once destroyed, the lid is no longer valid

↑ back to summary

🟢 VXI11-RULE-B.6.12 — device_abort does not affect destroy_link

Verifies:

• VXI-11 RULE B.6.12 destroy_link is not affected by device_abort.
• VXI-11 RULE B.6.106 device_abort initiates termination of any in-progress core channel RPC on the link except destroy_link, device_enable_srq and device_unlock, and returns error 0.

What is checked: destroy_link is one of the three procedures device_abort must leave alone; after an abort the link must still close cleanly

abort on idle link 0 -> 0 (no error)
destroy_link after abort -> 0 (no error)

↑ back to summary

🟢 VXI11-RULE-B.6.13 — device_write reports the number of bytes it accepted

Verifies:

• VXI-11 RULE B.6.13 device_write transfers data to the device, returns the number of bytes accepted in size, and returns error 0.

What is checked: Device_WriteResp.size is the count of bytes actually written

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)

↑ back to summary

🟢 VXI11-RULE-B.6.15 — Every operation on a destroyed link gives error 4

Verifies:

• VXI-11 RULE B.6.15 device_write with an unmatched lid returns error 4.
• VXI-11 RULE B.6.24 device_read with an unmatched lid returns error 4.
• VXI-11 RULE B.6.33 device_readstb with an unmatched lid returns error 4.
• VXI-11 RULE B.6.41 device_trigger with an unmatched lid returns error 4.
• VXI-11 RULE B.6.49 device_clear with an unmatched lid returns error 4.
• VXI-11 RULE B.6.57 device_remote with an unmatched lid returns error 4.
• VXI-11 RULE B.6.65 device_local with an unmatched lid returns error 4.
• VXI-11 RULE B.6.73 device_lock with an unmatched lid returns error 4 before any attempt to acquire the lock.
• VXI-11 RULE B.6.79 device_unlock with an unmatched lid returns error 4.
• VXI-11 RULE B.6.94 device_enable_srq with an unmatched lid returns error 4.
• VXI-11 RULE B.6.97 device_docmd with an unmatched lid returns error 4.

What is checked: 'invalid link identifier' is returned for any procedure taking a stale lid

device_write on stale lid -> 4 (invalid link identifier)
device_read on stale lid -> 4 (invalid link identifier)
device_readstb on stale lid -> 4 (invalid link identifier)
device_trigger on stale lid -> 4 (invalid link identifier)
device_clear on stale lid -> 4 (invalid link identifier)
device_remote on stale lid -> 4 (invalid link identifier)
device_local on stale lid -> 4 (invalid link identifier)
device_lock on stale lid -> 4 (invalid link identifier)
device_unlock on stale lid -> 4 (invalid link identifier)
device_enable_srq on stale lid -> 4 (invalid link identifier)
device_docmd on stale lid -> 4 (invalid link identifier)

↑ back to summary

🟢 VXI11-RULE-B.6.16 — device_write beyond maxRecvSize transfers nothing and returns error 5

Verifies:

• VXI-11 RULE B.6.16 device_write with data longer than maxRecvSize transfers nothing and returns error 5.

What is checked: data longer than the maxRecvSize reported by create_link must be rejected outright, not silently truncated or partially written

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
writing 1025 bytes with maxRecvSize=1024
-> 5 (parameter error), size=0

↑ back to summary

🟢 VXI11-RULE-B.6.17 — An operation from another link is refused while the device is locked

Verifies:

• VXI-11 RULE B.6.17 device_write against a lock held elsewhere blocks if waitlock is set, otherwise returns error 11.
• VXI-11 RULE B.6.25 device_read against a lock held elsewhere blocks if waitlock is set, otherwise returns error 11.
• VXI-11 RULE B.6.34 device_readstb against a lock held elsewhere blocks if waitlock is set, otherwise returns error 11.
• VXI-11 RULE B.6.42 device_trigger against a lock held elsewhere blocks if waitlock is set, otherwise returns error 11.
• VXI-11 RULE B.6.50 device_clear against a lock held elsewhere blocks if waitlock is set, otherwise returns error 11.
• VXI-11 RULE B.6.58 device_remote against a lock held elsewhere blocks if waitlock is set, otherwise returns error 11.
• VXI-11 RULE B.6.66 device_local against a lock held elsewhere blocks if waitlock is set, otherwise returns error 11.
• VXI-11 RULE B.6.101 device_docmd against a lock held elsewhere blocks if waitlock is set, otherwise returns error 11.

What is checked: without waitlock, operations on a locked device return error 11

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
device_write from the non-owning link -> 11 (device locked by another link)
device_read from the non-owning link -> 11 (device locked by another link)
device_readstb from the non-owning link -> 11 (device locked by another link)
device_clear from the non-owning link -> 11 (device locked by another link)

↑ back to summary

🟢 VXI11-RULE-B.6.18 — waitlock on an operation waits instead of failing immediately

Verifies:

• VXI-11 RULE B.6.18 device_write returns error 11 if the lock is still held after lock_timeout.
• VXI-11 RULE B.6.26 device_read returns error 11 with no data if the lock is still held after lock_timeout.
• VXI-11 RULE B.6.35 device_readstb returns error 11 if the lock is still held after lock_timeout.
• VXI-11 RULE B.6.43 device_trigger returns error 11 if the lock is still held after lock_timeout.
• VXI-11 RULE B.6.51 device_clear returns error 11 if the lock is still held after lock_timeout.
• VXI-11 RULE B.6.59 device_remote returns error 11 if the lock is still held after lock_timeout.
• VXI-11 RULE B.6.67 device_local returns error 11 if the lock is still held after lock_timeout.
• VXI-11 RULE B.6.102 device_docmd returns error 11 if the lock is still held after lock_timeout.

What is checked: the waitlock flag applies to every operation, not just device_lock

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
readstb with waitlock -> 11 (device locked by another link) after 1547 ms

↑ back to summary

🟢 VXI11-RULE-B.6.23-a — A write/read round trip returns instrument data with END set

Verifies:

• VXI-11 RULE B.6.23 device_read transfers bytes until END (sets END), requestSize reached (sets REQCNT, also used when requestSize is zero), termChar matched with termchrset (sets CHR), or the response buffer is full (sets no bit); then returns error 0.

What is checked: reason bit END (0x04) is set when the transfer ended on EOI/END

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
reason=0x04(END) data=b'HEWLETT-PACKARD,34401A,0,5-1-1\n'

↑ back to summary

🟢 VXI11-RULE-B.6.23-b — device_read never returns more than requestSize bytes

Verifies:

• VXI-11 RULE B.6.23 device_read transfers bytes until END (sets END), requestSize reached (sets REQCNT, also used when requestSize is zero), termChar matched with termchrset (sets CHR), or the response buffer is full (sets no bit); then returns error 0.

What is checked: the server must not transfer more than requestSize bytes

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
got 8 bytes, reason=0x01(REQCNT)

↑ back to summary

🟢 VXI11-RULE-B.6.23-c — termChar terminates a read and sets the CHR reason bit

Verifies:

• VXI-11 RULE B.6.23 device_read transfers bytes until END (sets END), requestSize reached (sets REQCNT, also used when requestSize is zero), termChar matched with termchrset (sets CHR), or the response buffer is full (sets no bit); then returns error 0.

What is checked: with termchrset the read ends on termChar and reason bit CHR (0x02) is set

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
reason=0x06(CHR|END) data=b'HEWLETT-PACKARD,34401A,0,5-1-1\n'

↑ back to summary

🟢 VXI11-RULE-B.6.23-d — device_read with requestSize zero terminates immediately with REQCNT

Verifies:

• VXI-11 RULE B.6.23 device_read transfers bytes until END (sets END), requestSize reached (sets REQCNT, also used when requestSize is zero), termChar matched with termchrset (sets CHR), or the response buffer is full (sets no bit); then returns error 0.

What is checked: the requestSize termination condition is the one to use when requestSize is zero, so the read returns at once with no data and the REQCNT bit set

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
requestSize=0 -> 0 (no error) reason=0x01(REQCNT) 0 bytes after 0 ms

↑ back to summary

🟢 VXI11-RULE-B.6.27 — device_read honours io_timeout and returns error 15

Verifies:

• VXI-11 RULE B.6.27 device_read returns error 15 with reason zero and the bytes transferred so far if the transfer exceeds io_timeout.
• VXI-11 RULE B.4.2 The server allows at least io_timeout milliseconds for an I/O operation to complete.
• VXI-11 RULE B.6.30 device_read returns the bytes transferred in data even when it ends in a timeout or an abort.

What is checked: when no data arrives within io_timeout the server returns 'I/O timeout'

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
read on an idle device: 15 (I/O timeout) after 2063 ms

↑ back to summary

🟢 VXI11-RULE-B.6.31 — device_readstb returns a status byte in range

Verifies:

• VXI-11 RULE B.6.31 device_readstb returns the device's status byte and error 0.
• VXI-11 RULE B.6.32 device_readstb returns error 8 if no status byte can be returned.

What is checked: device_readstb returns the instrument's status byte

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
stb = 0x00

↑ back to summary

🟢 VXI11-RULE-B.6.39 — device_trigger sends a trigger or reports error 8

Verifies:

• VXI-11 RULE B.6.39 device_trigger sends a trigger to the device and returns error 0.
• VXI-11 RULE B.6.40 device_trigger returns error 8 if the device has no trigger and the server can detect that.

What is checked: device_trigger triggers the device and returns 0; a server that can tell the device has no trigger returns 8 instead

Observed: device_trigger performed (error 0)

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
device_trigger on an idle, unlocked link -> 0 (no error)

↑ back to summary

🟢 VXI11-RULE-B.6.47 — device_clear clears the device or reports error 8

Verifies:

• VXI-11 RULE B.6.47 device_clear clears the device and returns error 0.
• VXI-11 RULE B.6.48 device_clear returns error 8 if the device has no clear and the server can detect that.

What is checked: device_clear performs a device clear and returns 0; a server that can tell the device has no clear returns 8 instead

Observed: device_clear performed (error 0)

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
device_clear on an idle, unlocked link -> 0 (no error)

↑ back to summary

🟢 VXI11-RULE-B.6.55 — device_remote sets the remote state or reports error 8

Verifies:

• VXI-11 RULE B.6.55 device_remote places the device in the remote state, error 0.
• VXI-11 RULE B.6.56 device_remote returns error 8 if the device has no remote state and the server can detect that.

What is checked: device_remote disables the front panel and returns 0, or returns 8 if the device has no remote state and the server can tell

Observed: device_remote performed (error 0)

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
device_remote on an idle, unlocked link -> 0 (no error)

↑ back to summary

🟢 VXI11-RULE-B.6.63 — device_local sets the local state or reports error 8

Verifies:

• VXI-11 RULE B.6.63 device_local places the device in the local state, error 0.
• VXI-11 RULE B.6.64 device_local returns error 8 if the device has no local state and the server can detect that.

What is checked: device_local re-enables the front panel and returns 0, or returns 8 if the device has no local state and the server can tell

Observed: device_local performed (error 0)

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
device_local on an idle, unlocked link -> 0 (no error)

↑ back to summary

🟢 VXI11-RULE-B.6.71 — device_lock succeeds on an unlocked device

Verifies:

• VXI-11 RULE B.6.71 device_lock acquires the device's lock and returns error 0.
• VXI-11 RULE B.6.78 device_unlock releases the lock and returns error 0.

What is checked: device_lock grants the lock and returns error 0

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)

↑ back to summary

🟢 VXI11-RULE-B.6.72 — device_lock from the link that already holds the lock gives error 11

Verifies:

• VXI-11 RULE B.6.72 device_lock from the link that already holds the lock returns error 11.

What is checked: the standard does not define nested locks: a second device_lock from the owning link returns 'device locked by another link'

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
second lock from the same link -> 11 (device locked by another link)

↑ back to summary

🟢 VXI11-RULE-B.6.74-a — A second link cannot lock a device that is already locked

Verifies:

• VXI-11 RULE B.6.74 device_lock against a lock held elsewhere blocks if waitlock is set, otherwise returns error 11.

What is checked: error 11 'device locked by another link'

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
link B lock without waitlock -> 11 (device locked by another link) after 0 ms

↑ back to summary

🟢 VXI11-RULE-B.6.74-b — waitlock acquires the lock as soon as the holder releases it

Verifies:

• VXI-11 RULE B.6.74 device_lock against a lock held elsewhere blocks if waitlock is set, otherwise returns error 11.

What is checked: a blocked device_lock completes when the lock becomes free

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
link B acquired after 1000 ms -> 0 (no error)

↑ back to summary

🟢 VXI11-RULE-B.6.75 — waitlock makes device_lock block for lock_timeout, then error 11

Verifies:

• VXI-11 RULE B.6.75 device_lock returns error 11 if the lock is still held after lock_timeout.

What is checked: with waitlock the server waits up to lock_timeout before returning error 11

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
link B waitlock(2000 ms) -> 11 (device locked by another link) after 2047 ms

↑ back to summary

🟢 VXI11-RULE-B.6.76 — device_abort terminates a blocked device_lock with error 23

Verifies:

• VXI-11 RULE B.6.76 device_lock returns error 23 when aborted.

What is checked: a device_lock waiting on the waitlock flag is an in-progress core channel RPC and must be abortable

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
device_abort on the blocked lock -> 0 (no error)
blocked device_lock returned 23 (abort) after 516 ms

↑ back to summary

🟢 VXI11-RULE-B.6.80-a — device_unlock without holding the lock gives error 12

Verifies:

• VXI-11 RULE B.6.80 device_unlock from a link that does not hold the lock returns error 12.

What is checked: 'no lock held by this link'

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)

↑ back to summary

🟢 VXI11-RULE-B.6.80-b — device_unlock from a link that does not own the lock gives error 12

Verifies:

• VXI-11 RULE B.6.80 device_unlock from a link that does not hold the lock returns error 12.

What is checked: only the owning link may unlock

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
link B unlock -> 12 (no lock held by this link)

↑ back to summary

🟢 VXI11-RULE-B.6.81 — device_abort does not affect device_unlock

Verifies:

• VXI-11 RULE B.6.81 device_unlock is not affected by device_abort.
• VXI-11 RULE B.6.106 device_abort initiates termination of any in-progress core channel RPC on the link except destroy_link, device_enable_srq and device_unlock, and returns error 0.

What is checked: device_unlock is exempt from abort: a lock must still be releasable after an abort was delivered on the link

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
abort -> 0 (no error)
device_unlock after abort -> 0 (no error)

↑ back to summary

🟢 VXI11-RULE-B.6.82 — create_intr_chan opens a channel back to the client

Verifies:

• VXI-11 RULE B.6.82 create_intr_chan establishes an interrupt channel to hostAddr and hostPort with the given program, version and family; error 0.
• VXI-11 RULE B.6.84 The server supports a TCP interrupt channel.
• VXI-11 RULE B.2.6 The interrupt channel is established by the server to the client after the client issues create_intr_chan.
• VXI-11 RULE B.6.91 destroy_intr_chan closes the interrupt channel and returns 0.

What is checked: the server connects to hostAddr/hostPort for interrupts

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
interrupt listener on 0.0.0.0:54299
create_intr_chan -> 192.168.3.3:54299

↑ back to summary

🟢 VXI11-RULE-B.6.83 — create_intr_chan with an unreachable address returns error 6

Verifies:

• VXI-11 RULE B.6.83 create_intr_chan returns error 6 if the channel cannot be established.

What is checked: an unusable interrupt address must yield an error, not a hung server

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
create_intr_chan to 192.0.2.1:9 -> 6 (channel not established) after 1.0s

↑ back to summary

🟢 VXI11-RULE-B.6.85 — create_intr_chan with an undefined progFamily returns error 8

Verifies:

• VXI-11 RULE B.6.85 create_intr_chan returns error 8 for a progFamily other than DEVICE_TCP or DEVICE_UDP.

What is checked: Device_AddrFamily has exactly two values, DEVICE_TCP and DEVICE_UDP; any other value is 'operation not supported'

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
interrupt listener on 0.0.0.0:54302
progFamily=7 -> 8 (operation not supported)

↑ back to summary

🟢 VXI11-RULE-B.6.86 — create_intr_chan with progFamily=UDP is handled

Verifies:

• VXI-11 RULE B.6.86 create_intr_chan returns error 8 for a protocol the server does not support, such as UDP.
• VXI-11 PERM B.6.1 The server may support a UDP interrupt channel.

What is checked: Device_AddrFamily may be DEVICE_TCP or DEVICE_UDP

Observed: UDP interrupt channels -> 8 (operation not supported)

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
interrupt listener on 0.0.0.0:61339
create_intr_chan(DEVICE_UDP) -> 8 (operation not supported)

↑ back to summary

🟢 VXI11-RULE-B.6.87 — create_intr_chan with a progNum other than 395185 returns error 8

Verifies:

• VXI-11 RULE B.6.87 create_intr_chan returns error 8 if progNum is not 395185.

What is checked: the interrupt channel program number is fixed; anything else is 'operation not supported'

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
interrupt listener on 0.0.0.0:61341
progNum=0x0607B2 -> 8 (operation not supported)

↑ back to summary

🟢 VXI11-RULE-B.6.88 — create_intr_chan with a progVers other than 1 returns error 8

Verifies:

• VXI-11 RULE B.6.88 create_intr_chan returns error 8 if progVers is not 1.

What is checked: only version 1 of the interrupt program is defined

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
interrupt listener on 0.0.0.0:61343
progVers=2 -> 8 (operation not supported)

↑ back to summary

🟢 VXI11-RULE-B.6.89 — create_intr_chan twice gives error 29

Verifies:

• VXI-11 RULE B.6.89 create_intr_chan when a channel already exists performs no operation and returns error 29.
• VXI-11 RULE B.2.9 create_intr_chan when a channel already exists does not create a new one; one interrupt channel serves all links on the connection.

What is checked: 'channel already established' when one is already open

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
interrupt listener on 0.0.0.0:61345
create_intr_chan -> 192.168.3.3:61345
create_intr_chan -> 192.168.3.3:61345
second create_intr_chan -> 29 (channel already established)

↑ back to summary

🟢 VXI11-RULE-B.6.90 — The server works normally when no interrupt channel is established

Verifies:

• VXI-11 RULE B.6.90 The server operates correctly even with no interrupt channel.

What is checked: a client that never calls create_intr_chan must see a fully functional server

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)

↑ back to summary

🟢 VXI11-RULE-B.6.92 — destroy_intr_chan without a channel gives error 6

Verifies:

• VXI-11 RULE B.6.92 destroy_intr_chan with no channel open returns error 6.

What is checked: destroying a channel that was never created is an error

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
destroy_intr_chan with no channel -> 6 (channel not established)

↑ back to summary

🟢 VXI11-RULE-B.6.93-a — device_enable_srq accepts a 40-byte handle

Verifies:

• VXI-11 RULE B.6.93 device_enable_srq enables or disables interrupts for this link and stores the handle unmodified; error 0.

What is checked: handles up to 40 bytes must be accepted verbatim

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
interrupt listener on 0.0.0.0:61349
create_intr_chan -> 192.168.3.3:61349

↑ back to summary

🟢 VXI11-RULE-B.6.93-b — device_enable_srq works when no interrupt channel is open

Verifies:

• VXI-11 RULE B.6.93 device_enable_srq enables or disables interrupts for this link and stores the handle unmodified; error 0.
• VXI-11 OBS B.6.21 Service request enable states are per link and survive interrupt channel creation and destruction.

What is checked: the enable state is per link and survives interrupt channel creation and destruction, so device_enable_srq must succeed even with no channel open; Table B.18 allows only errors 0 and 4

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
device_enable_srq before create_intr_chan -> 0 (no error)

↑ back to summary

🟢 VXI11-RULE-B.6.95 — device_enable_srq behaves the same whether or not the link is locked

Verifies:

• VXI-11 RULE B.6.95 device_enable_srq behaves the same whether or not the link holds the lock.

What is checked: enabling interrupts is independent of locking: it must not return error 11 when another link holds the lock, and it must not block

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
device_enable_srq from an unlocked link -> 0 (no error) after 0 ms

↑ back to summary

🟢 VXI11-RULE-B.6.98 — device_docmd rejects an unsupported cmd with error 8

Verifies:

• VXI-11 RULE B.6.98 device_docmd returns error 8 for a cmd value it does not support.
• VXI-11 PERM B.6.2 A server may support none, some or all cmd values in device_docmd.

What is checked: cmd values are defined by the companion documents; a server may support none of them, but an unsupported cmd must come back as 'operation not supported' rather than as a generic failure

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
device_docmd(cmd=0x7EEE0001) -> 8 (operation not supported)

↑ back to summary

🟢 VXI11-RULE-B.6.107 — device_abort terminates an in-progress read with error 23

Verifies:

• VXI-11 RULE B.6.107 After replying to device_abort the server replies to the aborted call with error 23.
• VXI-11 RULE B.6.106 device_abort initiates termination of any in-progress core channel RPC on the link except destroy_link, device_enable_srq and device_unlock, and returns error 0.
• VXI-11 RULE B.6.29 device_read returns error 23 if device_abort is called during it.

What is checked: an aborted operation returns 'abort' (error 23) promptly

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
device_abort -> 0 (no error)
pending read returned 23 (abort) after 578 ms

↑ back to summary

🟢 VXI11-RULE-B.6.108 — device_abort with an unknown link identifier gives error 4

Verifies:

• VXI-11 RULE B.6.108 device_abort with an unmatched lid returns error 4.

What is checked: device_abort validates the lid like every other procedure

↑ back to summary

🟢 VXI11-RULE-B.6.109 — device_abort works while another link holds the lock

Verifies:

• VXI-11 RULE B.6.109 device_abort is not affected by locking.

What is checked: the operation of device_abort is not affected by locking, so it must never return error 11 or wait for a lock

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
device_abort on the unlocked link -> 0 (no error) after 0 ms

↑ back to summary

🟢 VXI11-RULE-B.6.111 — An SRQ is delivered with the exact handle that was registered

Verifies:

• VXI-11 RULE B.6.111 device_intr_srq carries back the handle exactly as received in device_enable_srq.
• VXI-11 RULE B.6.110 device_intr_srq is sent only when interrupts are enabled for the link and an interrupt channel exists.
• VXI-11 RULE B.3.1 Interrupt messages use the given RPCL: device_intr_srq, procedure 30, program 0x0607B1, version 1, returning void.

What is checked: device_intr_srq carries back the handle unchanged

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
interrupt listener on 0.0.0.0:61361
create_intr_chan -> 192.168.3.3:61361
SRQ from ('192.168.3.2', 44511) with handle b'CONFORM-SRQ-01'

↑ back to summary

🟢 VXI11-RULE-C.1 — Error replies still carry the complete result structure

Verifies:

• VXI-11 RULE C.1 The host implements the RPCL constructs of section C, including the full result structures of each reply.
• VXI-11 RULE B.1.3 Messages are ONC/RPC compatible and use XDR at the presentation layer.

What is checked: Device_ReadResp, Device_WriteResp and Device_ReadStbResp are structs, not unions: every member is encoded even when error != 0

device_read error reply body = 12 bytes (expected >= 12)
device_write error reply body = 8 bytes (expected >= 8)
device_readstb error reply body = 8 bytes (expected >= 8)

↑ back to summary

🟢 VXI11-REC-B.2.1 — The abort channel is reachable while the core channel is busy

Verifies:

• VXI-11 REC B.2.1 The abort channel should respond in a timely manner.

What is checked: the abort channel must be serviced independently of in-progress core operations

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
device_abort answered in 15 ms -> 0 (no error)

↑ back to summary

🟢 VXI11-REC-B.4.2 — Several links can be used concurrently without cross-talk

Verifies:

• VXI-11 REC B.4.2 An instrument's host should route at least two links to any device.
• VXI-11 RULE B.2.4 RPCs performing I/O to the same device or interface are serialized.

What is checked: concurrent links are independent sessions

↑ back to summary

🟢 VXI11-REC-B.6.1 — A second link can be opened on the same device

Verifies:

• VXI-11 REC B.6.1 A server should maintain at least two links on one connection.

What is checked: multiple links to one device are allowed; refusal must be error 9

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)

↑ back to summary

🟢 VXI11-OBS-B.6.6 — A zero-length write is handled cleanly

Verifies:

• VXI-11 OBS B.6.6 device_write with a zero-length data parameter performs no device action.

What is checked: an empty data parameter is legal; it must not hang or error out oddly

Observed: empty write -> 0 (no error)

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
empty write -> 0 (no error) size=0

↑ back to summary

🟢 VXI11-EXT-ABT-001 — The abort channel accepts an RPC null call

Beyond the standard — this check has no counterpart in VXI-11; it covers interoperability or robustness the specification leaves open.

What is checked: the abort channel is a separate, always-available RPC service

abort channel NULL -> MSG_ACCEPTED/SUCCESS

↑ back to summary

🟢 VXI11-EXT-ABT-005 — device_abort with nothing in progress is harmless

Beyond the standard — this check has no counterpart in VXI-11; it covers interoperability or robustness the specification leaves open.

What is checked: an abort with no operation pending is not an error condition

Observed: idle abort -> 0 (no error)

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
idle device_abort -> 0 (no error)

↑ back to summary

🟢 VXI11.2-EXT-CMD-001 — Bus Status rejects an undefined subcode

Beyond the standard — this check has no counterpart in VXI-11; it covers interoperability or robustness the specification leaves open.

What is checked: Table B.2 defines subcodes 1 to 8; the standard does not say what happens for others, so this only records the behaviour

Observed: subcode 99 -> 5 (parameter error)

interface link 0 on 'gpib0'
subcode 99 -> 5 (parameter error) (0 bytes)

↑ back to summary

🟢 VXI11.2-EXT-CMD-002 — Send Command respects the 128 byte limit

Verifies:

• VXI-11.2 RULE B.5.3 A data_in_len or datasize conflicting with Table B.1 gives error 5 and no action; datasize X accepts any value.

What is checked: Table B.1 allows data_in_len 0 to 128 for Send Command; more than that conflicts with the table and should be a parameter error (RULE B.5.3)

interface link 0 on 'gpib0'
129 command bytes -> 5 (parameter error)

↑ back to summary

🟢 VXI11-EXT-GEN-001 — The generic operations leave the link usable

Beyond the standard — this check has no counterpart in VXI-11; it covers interoperability or robustness the specification leaves open.

What is checked: trigger, clear, remote and local in sequence must not wedge the link or the server -- a practical follow-up to B.6.39 to B.6.70

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
device_trigger -> 0 (no error)
device_clear -> 0 (no error)
device_remote -> 0 (no error)
device_local -> 0 (no error)

↑ back to summary

🟢 VXI11-EXT-INT-005 — A handle longer than 40 bytes is a parameter error

Beyond the standard — this check has no counterpart in VXI-11; it covers interoperability or robustness the specification leaves open.

What is checked: Device_EnableSrqParms.handle is opaque<40>

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
interrupt listener on 0.0.0.0:53273
create_intr_chan -> 192.168.3.3:53273
41-byte handle -> 5 (parameter error)

↑ back to summary

🟢 VXI11-EXT-IO-005 — termChar outside 0..255 is a parameter error

Beyond the standard — this check has no counterpart in VXI-11; it covers interoperability or robustness the specification leaves open.

What is checked: error 5 when termchrset is set and termChar is not a valid character

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
termChar=0x1234 -> 5 (parameter error)

↑ back to summary

🟢 VXI11-EXT-IO-010 — A write without the END flag does not terminate the message

Verifies:

• VXI-11 RULE B.6.14 With the end flag set, an END indicator accompanies the last byte.

What is checked: END (0x08) sets EOI on the last byte; without it the message continues

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
split write '*I' + 'DN?\n' -> 0 (no error) b'HEWLETT-PACKARD,34401A,0,5-1-1\n'

↑ back to summary

🟢 VXI11-EXT-IO-011 — device_read on a device with nothing pending does not return stale data

Beyond the standard — this check has no counterpart in VXI-11; it covers interoperability or robustness the specification leaves open.

What is checked: each read reflects the current transfer, not a cached buffer

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
follow-up read -> 15 (I/O timeout) b''

↑ back to summary

🟢 VXI11-EXT-IO-012 — Reserved bits in Device_Flags are ignored, not rejected

Beyond the standard — this check has no counterpart in VXI-11; it covers interoperability or robustness the specification leaves open.

What is checked: only bits 0, 3 and 7 are defined; the rest are reserved

Observed: reserved flag bit -> 0 (no error)

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
device_write with flags=0x48 -> 0 (no error)

↑ back to summary

🟢 VXI11-EXT-LCK-007 — The lock owner can still use the device

Verifies:

• VXI-11 OBS B.6.18 The server blocks when another link holds the lock, but not merely because another link is doing I/O.

What is checked: the holding link operates normally while locked

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)

↑ back to summary

🟢 VXI11-EXT-LNK-003 — abortPort matches the port mapper's DEVICE_ASYNC entry

Beyond the standard — this check has no counterpart in VXI-11; it covers interoperability or robustness the specification leaves open.

What is checked: abortPort identifies the abort channel for this link

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)

↑ back to summary

🟢 VXI11-EXT-LNK-006 — create_link on a nonexistent device name is refused

Beyond the standard — this check has no counterpart in VXI-11; it covers interoperability or robustness the specification leaves open.

What is checked: an unknown device gives error 3 (not accessible) or 21 (invalid address)

↑ back to summary

🟢 VXI11-EXT-LNK-007 — create_link with a syntactically invalid device name is refused

Beyond the standard — this check has no counterpart in VXI-11; it covers interoperability or robustness the specification leaves open.

What is checked: device names follow inst / gpib[,[,]]

create_link('!!!not a device!!!') -> 5 (parameter error)
create_link('gpib0,not_a_number') -> 5 (parameter error)
create_link('xxxxxxxxxxxxxxxxxxxxxxxx') -> 5 (parameter error)

↑ back to summary

🟢 VXI11-EXT-LNK-011 — A link is not usable from a different core connection

Beyond the standard — this check has no counterpart in VXI-11; it covers interoperability or robustness the specification leaves open.

What is checked: links belong to the channel that created them; a foreign lid is invalid

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
readstb on connection B with A's lid -> 4 (invalid link identifier)

↑ back to summary

🟢 VXI11-EXT-PM-003 — DEVICE_ASYNC (0x0607B0) v1 is registered

Beyond the standard — this check has no counterpart in VXI-11; it covers interoperability or robustness the specification leaves open.

What is checked: not required: VXI-11 delivers the abort port in the create_link reply (RULE B.6.3) and only the core channel is registered with the port mapper (Figure B.12). Registering the abort program too is harmless and helps tools that go looking for it.

abort channel on port 34568

↑ back to summary

🟢 VXI11-EXT-PM-004 — GETPORT for an unregistered program returns 0, not an error

Beyond the standard — this check has no counterpart in VXI-11; it covers interoperability or robustness the specification leaves open.

What is checked: GETPORT yields port 0 when no mapping exists

↑ back to summary

🟢 VXI11-EXT-PM-005 — GETPORT for a wrong version of DEVICE_CORE does not resolve to v1

Beyond the standard — this check has no counterpart in VXI-11; it covers interoperability or robustness the specification leaves open.

What is checked: mappings are per (prog, vers, prot)

↑ back to summary

🟢 VXI11-EXT-PM-008 — Port mapper handles PMAPPROC_DUMP or rejects it cleanly

Beyond the standard — this check has no counterpart in VXI-11; it covers interoperability or robustness the specification leaves open.

What is checked: DUMP is optional in practice; it must not wedge the server

Observed: DUMP supported

PMAPPROC_DUMP -> MSG_ACCEPTED/SUCCESS

↑ back to summary

🟢 VXI11-EXT-PM-009 — Port mapper survives a GETPORT with truncated arguments

Beyond the standard — this check has no counterpart in VXI-11; it covers interoperability or robustness the specification leaves open.

What is checked: undecodable arguments give GARBAGE_ARGS, not a dropped service

truncated GETPORT -> no reply within 15.0s from 192.168.3.2:111

↑ back to summary

🟢 VXI11-EXT-ROB-003 — A very large requestSize does not upset the server

Beyond the standard — this check has no counterpart in VXI-11; it covers interoperability or robustness the specification leaves open.

What is checked: requestSize is a u_long; the server must clamp it, not trust it

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
requestSize=0x7FFFFFFF -> 15 (I/O timeout), 0 bytes

↑ back to summary

🟢 VXI11-EXT-ROB-005 — Bare TCP connects and disconnects do not exhaust the server

Beyond the standard — this check has no counterpart in VXI-11; it covers interoperability or robustness the specification leaves open.

What is checked: half-open or abandoned connections must be cleaned up

↑ back to summary

🟢 VXI11-EXT-ROB-006 — The server is still healthy at the end of the run

Beyond the standard — this check has no counterpart in VXI-11; it covers interoperability or robustness the specification leaves open.

What is checked: Sanity check: everything above must leave the device usable

link 0 opened on 'gpib0,4' (maxRecvSize=1024 abortPort=34568)
final readstb -> 0 (no error)

↑ back to summary

🟢 VXI11-EXT-RPC-004 — Truncated arguments give GARBAGE_ARGS rather than a dropped connection

Verifies:

• VXI-11 RULE B.1.3 Messages are ONC/RPC compatible and use XDR at the presentation layer.

What is checked: undecodable arguments are reported as GARBAGE_ARGS

truncated create_link -> MSG_ACCEPTED/GARBAGE_ARGS

↑ back to summary

🟢 VXI11-EXT-RPC-005 — An RPC version other than 2 is denied with RPC_MISMATCH

Verifies:

• VXI-11 RULE B.1.3 Messages are ONC/RPC compatible and use XDR at the presentation layer.

What is checked: MSG_DENIED/RPC_MISMATCH when rpcvers != 2

rpcvers=3 -> MSG_DENIED/RPC_MISMATCH (low=2 high=2)

↑ back to summary

🟢 VXI11-EXT-RPC-006 — The reply carries the transaction id of the call

Verifies:

• VXI-11 RULE B.1.3 Messages are ONC/RPC compatible and use XDR at the presentation layer.

What is checked: the xid of a reply matches the call it answers

xid sent 0x0badc0de, received 0x0badc0de

↑ back to summary

🟢 VXI11-EXT-RPC-007 — A call split across several record fragments is reassembled

Verifies:

• VXI-11 RULE B.1.3 Messages are ONC/RPC compatible and use XDR at the presentation layer.

What is checked: record marking allows any fragmentation; the last fragment sets the high bit

fragmented create_link -> MSG_ACCEPTED/SUCCESS

↑ back to summary

🟢 VXI11-EXT-RPC-008 — AUTH_UNIX credentials are accepted

Verifies:

• VXI-11 RULE B.1.3 Messages are ONC/RPC compatible and use XDR at the presentation layer.

What is checked: servers that require no authentication must still accept AUTH_UNIX

AUTH_UNIX create_link -> MSG_ACCEPTED/SUCCESS

↑ back to summary

🟢 VXI11-EXT-RPC-009 — The reply verifier is AUTH_NONE with an empty body

Verifies:

• VXI-11 RULE B.1.3 Messages are ONC/RPC compatible and use XDR at the presentation layer.

What is checked: a server that does not authenticate replies with a null verifier

reply verf flavor=0 len=0

↑ back to summary

🟢 VXI11-EXT-RPC-011 — The server survives garbage on the core port

Beyond the standard — this check has no counterpart in VXI-11; it covers interoperability or robustness the specification leaves open.

What is checked: malformed input must not take the service down

post-garbage create_link -> MSG_ACCEPTED/SUCCESS

↑ back to summary

Generated by make_report.py from report.json.

GPIBee DUT details:

• Serial#: LJPAT, FW: V1.5.2608231401

Table of contents

• Summarized testcase results
• Detailed testcase logs
  • basic_gpib_primitives
  • basic_vxi-11_connectiontest
  • exclusivelock_check_unlocked_link_behavior
  • exclusivelock_does_destroy_link_unlock
  • exclusivelock_multiple_lockcalls
  • exclusivelock_simple
  • instancenames
  • internal_scpi_param_change
  • internal_scpi_param_defaults
  • internal_scpi_param_limits
  • io_timeout
  • lock_on_link_creation
  • lock_timeout
  • max_connectioncount
  • scan
  • timeout_behavior_on_locked_link_with_no_wait_lock
  • timeout_extension_by_lock
  • unsynchronized_simultaneous_access

Summarized testcase results

Overall result: ✅ PASSED

Total duration: ⏱ 52.183 seconds

Detailed testcase logs

basic_gpib_primitives

Testcase description

Test some basic GPIB functionality: Clearing, triggering, status byte reading. This testcases expects a HP3458A on GPIB address 22.

Log

Using visa provider: rs

Subtest: Trying to read measurement results from the instrument in auto trigger mode.

Result of 5 reads: 2.3713700E+00\r\n / 2.3715830E+00\r\n / 2.3716510E+00\r\n / 2.3713800E+00\r\n / 2.3715860E+00\r\n

Subtest: Clearing and trying to read. If clear was successful we should run into a timeout.

As expected, we ran into a timeout.

Subtest: Testing Status byte reading

Status byte reading worked. Value = 0x58

Subtest: Testing trigger function

Results: 2.3793640E+00\r\n / [read did not work as exepected] / 2.3799860E+00\r\n / [read did not work as exepected] / 2.3810750E+00\r\n / [read did not work as exepected] / 2.3827190E+00\r\n / [read did not work as exepected]

Trigger functionality confirmed working.

Subtest: Test read termination setting

response parts: part1 = "HP34", part2 = "57A\r\n"

Read termination setting worked correctly.

disabling read termination character and reading ID? query again

Query response: HP3457A\r\n

response is correct as expected

Subtest: Testing SRQ signalling

SRQ properly signalled

Summary: - test result: ✅ PASSED - duration: 9.063s

basic_vxi-11_connectiontest

Testcase description

Basic vxi-11 connection test. Used also to query GPIBee FW version / serial number for logging purposes

Log

Using visa provider: pyvisa-py

Creating link

Execute *IDN? query

Summary: - test result: ✅ PASSED - duration: 0.013s

exclusivelock_check_unlocked_link_behavior

Testcase description

Test locking behavior on unlocked instance.

Log

Using visa provider: pyvisa-py

1st Query failed as expected

2nd Query result = XYPHROLABS,GPIBEE,LJPAT,V1.5.2608231401\r\n

Summary: - test result: ✅ PASSED - duration: 0.049s

exclusivelock_does_destroy_link_unlock

Testcase description

Test if destroying a link does remove a lock

Log

Using visa provider: pyvisa-py

Creating first link

Creating second link

Lock 2nd link

Trying if 1st link is really locked as expected

1st Query failed as expected

destroying 2nd link

trying if 1st link is responsive

2nd Query result = XYPHROLABS,GPIBEE,LJPAT,V1.5.2608231401\r\n

Summary: - test result: ✅ PASSED - duration: 0.019s

exclusivelock_multiple_lockcalls

Testcase description

Test if multiple lock and unlock tries return an error on 2nd, 3rd, ... lock and not on 1st.

Log

Using visa provider: pyvisa-py

Checking multiple lock behavior

Trying Lock #1

Locking worked without error

Trying Lock #2

Lock returned an error

Trying Lock #3

Lock returned an error

Trying Lock #4

Lock returned an error

Checking multiple unlock behavior

Trying Unlock #1

Unlocking worked without error

Trying Unlock #2

Unlock returned an error

Trying Unlock #3

Unlock returned an error

Trying Unlock #4

Unlock returned an error

Summary: - test result: ✅ PASSED - duration: 0.016s

exclusivelock_simple

Testcase description

create a link, lock it, then create a new link and check if opening fails as expected

Log

Using visa provider: pyvisa-py

opening ressource TCPIP::192.168.3.2::inst0::INSTR

Locking device

Trying to open a 2nd instance to the same device

Summary: - test result: ✅ PASSED - duration: 0.006s

instancenames

Testcase description

Trying to open different flavors of VXI-11 instance names

Log

Using visa provider: pyvisa-py

opening ressource TCPIP::192.168.3.2::inst0::INSTR

opened successfully

opening ressource TCPIP::192.168.3.2::gpib0::INSTR

opened successfully

opening ressource TCPIP::192.168.3.2::hpib0::INSTR

opened successfully

opening ressource TCPIP::192.168.3.2::inst,22::INSTR

open failed

opening ressource TCPIP::192.168.3.2::gpib,22::INSTR

open failed

opening ressource TCPIP::192.168.3.2::hpib,22::INSTR

open failed

opening ressource TCPIP::192.168.3.2::inst0,22::INSTR

opened successfully

opening ressource TCPIP::192.168.3.2::gpib0,22::INSTR

opened successfully

opening ressource TCPIP::192.168.3.2::hpib0,22::INSTR

opened successfully

opening ressource TCPIP::192.168.3.2::inst1::INSTR

open failed

opening ressource TCPIP::192.168.3.2::gpib1::INSTR

open failed

opening ressource TCPIP::192.168.3.2::inst0,240::INSTR

open failed

Summary: - test result: ✅ PASSED - duration: 0.033s

internal_scpi_param_change

Testcase description

Check the internal scpi command parameters can be changed.

Log

Using visa provider: pyvisa-py

Creating link

Resetting settings to presets

Trying to apply new values

Reading out default values

Resetting settings to presets

Parameter name	New value applied	Actual value	Passed?
SYSTem:COMMunicate:LAN:IPADdress	"10.0.0.5"	"10.0.0.5"	PASSED
SYSTem:COMMunicate:LAN:SUBNet	"255.255.0.0"	"255.255.0.0"	PASSED
SYSTem:COMMunicate:LAN:DHCP	OFF	OFF	PASSED
SYSTem:COMMunicate:LAN:MDNS	OFF	OFF	PASSED
SYSTem:COMMunicate:LAN:SSDP	OFF	OFF	PASSED
SYSTem:COMMunicate:LAN:HOSTname	"MYDEVICE"	"MYDEVICE"	PASSED
SYSTem:COMMunicate:LAN:DHCP:TIMEout	11	11	PASSED
SYSTem:COMMunicate:LAN:PPprot	OFF	OFF	PASSED
SYSTem:COMMunicate:USB:FALLback	15	15	PASSED
SYSTem:COMMunicate:USB:FORCEfullspeed	ON	ON	PASSED
SYSTem:COMMunicate:USBTMC:NAME	"USBTMCDEVICE"	"USBTMCDEVICE"	PASSED
SYSTem:COMMunicate:USBTMC:DELAY	10	10	PASSED
SYSTem:COMMunicate:USBTMC:AUTOidRETry	13	13	PASSED
SYSTem:COMMunicate:USBTMC:SCANSTARTaddr	2	2	PASSED
SYSTem:COMMunicate:USB:PROTocol	USBTMC	USBTMC	PASSED
SYSTem:COMMunicate:GPIB:T1TIME	700	700	PASSED
SYSTem:COMMunicate:USBNET:IPADdress	"192.168.5.2"	"192.168.5.2"	PASSED
SYSTem:COMMunicate:VXI11:PRESENCEcheck	OFF	OFF	PASSED
SYSTem:COMMunicate:VXI11:MINimumIOTimeOut	42	42	PASSED
SYSTem:COMMunicate:VXI11:MAXimumIOTimeOut	1600	1600	PASSED
SYSTem:COMMunicate:VXI11:SRQAUTOpoll	ON	ON	PASSED
SYSTem:COMMunicate:USBTMC:suppressIDN	ON	ON	PASSED
SYSTem:COMMunicate:GPIB:CTRLADdress	22	22	PASSED

Summary: - test result: ✅ PASSED - duration: 1.189s

internal_scpi_param_defaults

Testcase description

Test the the internal SCPI adjustable parameters have correct default settings.

Log

Using visa provider: pyvisa-py

Creating link

Resetting settings to presets

Reading out default values

Parameter name	Expected default value	Actual default value	Correct?
SYSTem:COMMunicate:LAN:IPADdress	"192.168.1.2"	"192.168.1.2"	correct
SYSTem:COMMunicate:LAN:SUBNet	"255.255.255.0"	"255.255.255.0"	correct
SYSTem:COMMunicate:LAN:DHCP	ON	ON	correct
SYSTem:COMMunicate:LAN:MDNS	ON	ON	correct
SYSTem:COMMunicate:LAN:SSDP	ON	ON	correct
SYSTem:COMMunicate:LAN:HOSTname	"GPIBEE-{UID}"	"GPIBEE-{UID}"	correct
SYSTem:COMMunicate:LAN:DHCP:TIMEout	15	15	correct
SYSTem:COMMunicate:LAN:PPprot	ON	ON	correct
SYSTem:COMMunicate:USB:FALLback	4	4	correct
SYSTem:COMMunicate:USB:FORCEfullspeed	OFF	OFF	correct
SYSTem:COMMunicate:USBTMC:NAME	"GPIB-{ADDR}-{UID}"	"GPIB-{ADDR}-{UID}"	correct
SYSTem:COMMunicate:USBTMC:DELAY	1	1	correct
SYSTem:COMMunicate:USBTMC:AUTOidRETry	0	0	correct
SYSTem:COMMunicate:USBTMC:SCANSTARTaddr	1	1	correct
SYSTem:COMMunicate:USB:PROTocol	NET	NET	correct
SYSTem:COMMunicate:USBNET:IPADdress	"192.168.3.2"	"192.168.3.2"	correct
SYSTem:COMMunicate:VXI11:PRESENCEcheck	ON	ON	correct
SYSTem:COMMunicate:VXI11:MINimumIOTimeOut	10	10	correct
SYSTem:COMMunicate:VXI11:SRQAUTOpoll	OFF	OFF	correct
SYSTem:COMMunicate:GPIB:T1TIME	500	500	correct
SYSTem:COMMunicate:VXI11:MAXimumIOTimeOut	30000	30000	correct
SYSTem:COMMunicate:USBTMC:suppressIDN	OFF	OFF	correct
SYSTem:COMMunicate:GPIB:CTRLADdress	0	0	correct

Summary: - test result: ✅ PASSED - duration: 0.076s

internal_scpi_param_limits

Testcase description

Test if boundary/correctness checks on internal SCPI commands parameter set functions work.

Log

Using visa provider: pyvisa-py

Creating link

Resetting settings to presets

Applying on purpose wrong values

Resetting settings to presets

Parameter name	Incorrect value applied	Expected value	Actual value	Passed?
SYSTem:COMMunicate:LAN:IPADdress	"224.168.1.2"	"192.168.1.2"	"192.168.1.2"	PASSED
SYSTem:COMMunicate:LAN:SUBNet	"255.255.6.255"	"255.255.0.0"	"255.255.0.0"	PASSED
SYSTem:COMMunicate:LAN:DHCP	2	ON	ON	PASSED
SYSTem:COMMunicate:LAN:MDNS	-1	ON	ON	PASSED
SYSTem:COMMunicate:LAN:SSDP	5	ON	ON	PASSED
SYSTem:COMMunicate:LAN:HOSTname	"GPIBEE- {UID}"	"GPIBEE-{UID}"	"GPIBEE-{UID}"	PASSED
SYSTem:COMMunicate:LAN:DHCP:TIMEout	1000	30	30	PASSED
SYSTem:COMMunicate:LAN:PPprot	3	ON	ON	PASSED
SYSTem:COMMunicate:USB:FALLback	-1	30	30	PASSED
SYSTem:COMMunicate:USB:FORCEfullspeed	4	OFF	OFF	PASSED
SYSTem:COMMunicate:USBTMC:NAME	"-GPIB-{ADDR}{UID}"	"GPIB-{ADDR}_{UID}"	"GPIB-{ADDR}_{UID}"	PASSED
SYSTem:COMMunicate:USBTMC:DELAY	1000	30	30	PASSED
SYSTem:COMMunicate:USBTMC:AUTOidRETry	1000	600	600	PASSED
SYSTem:COMMunicate:USBTMC:SCANSTARTaddr	31	30	30	PASSED
SYSTem:COMMunicate:USB:PROTocol	ETHERNET	NET	NET	PASSED
SYSTem:COMMunicate:USBNET:IPADdress	"224.0.0.0"	"192.168.3.2"	"192.168.3.2"	PASSED
SYSTem:COMMunicate:VXI11:PRESENCEcheck	7	ON	ON	PASSED
SYSTem:COMMunicate:VXI11:SRQAUTOpoll	5	OFF	OFF	PASSED
SYSTem:COMMunicate:GPIB:T1TIME	2500	2000	2000	PASSED
SYSTem:COMMunicate:GPIB:T1TIME	0	350	350	PASSED
SYSTem:COMMunicate:VXI11:MINimumIOTimeOut	20000	5000	5000	PASSED
SYSTem:COMMunicate:VXI11:MAXimumIOTimeOut	480000	30000	30000	PASSED
SYSTem:COMMunicate:USBTMC:suppressIDN	5	OFF	OFF	PASSED
SYSTem:COMMunicate:GPIB:CTRLADdress	32	30	30	PASSED

Summary: - test result: ✅ PASSED - duration: 0.631s

io_timeout

Testcase description

Test if io timeout values are correctly considered. Made for HP3457a on GPIB address 22.

Note, that the measured values include additional overhead and is not a pure measurement of network call to reply time.

Log

Allowed timing inaccuracy: 800.0ms

Using visa provider: rs

Creating link

Ensuring that the instrument is not responding to reads.

Starting IO timeout measurement

Testing timeout of 5000.0ms

Testing timeout of 2000.0ms

Testing timeout of 1000.0ms

Testing timeout of 100.0ms

Testing timeout of 10.0ms

Requested timeout duration [ms]	Actual measured timeout duration [ms]	Actual - measured duration [ms]
5000.000	5026.149	26.149
2000.000	2062.899	62.899
1000.000	1030.070	30.070
100.000	129.161	29.161
10.000	34.036	24.036

Summary: - test result: ✅ PASSED - duration: 8.823s

lock_on_link_creation

Testcase description

Test several VXI-11 locking scenarios where link creation is involved.

Log

TRY 1 with VXI11 GPIB device presence check in state ON

Testing if opening a device with lock requested does really lock

SUCCESS: CREATE_LINK with LockDevice=1 does lock the device as expected

Testing if opening a locked device works when the new connection is done without lock (Rule B.6.6).

SUCCESS: CREATE_LINK with LockDevice=0 is manages to connect to a command

Summary: - test result: ✅ PASSED - duration: 1.074s

lock_timeout

Testcase description

Test if lock timeout values are correctly considered. Uses HP3457a on GPIB address 22.

Note, that the measured values include additional overhead and is not a pure measurement of network call to reply time.

Log

Allowed timing inaccuracy: 150.0ms

Using visa provider: rs

Creating 1st link - used to lock and unlock instrument

Ensuring that instrument is in auto trigger mode via 1st link

Creating 2nd link - used to measure lock timeout duration

Locking via 1st link the instrument (2nd link is already acquired)

Starting IO timeout measurement

Testing timeout of 5000.0ms

Testing timeout of 2000.0ms

Testing timeout of 1000.0ms

Testing timeout of 100.0ms

Testing timeout of 10.0ms

Requested timeout duration [ms]	Actual measured timeout duration [ms]	Actual - measured duration [ms]
5000.000	5050.052	50.052
2000.000	2051.148	51.148
1000.000	1051.458	51.458
100.000	151.293	51.293
10.000	60.652	50.652

Summary: - test result: ✅ PASSED - duration: 8.472s

max_connectioncount

Testcase description

Test how many concurrent connections can be made. This test tests VXI-11 server stack limits.

Log

Using visa provider: rs

Creating link #1

Communication with all 1 active connections worked

Creating link #2

Communication with all 2 active connections worked

Creating link #3

Communication with all 3 active connections worked

Creating link #4

Communication with all 4 active connections worked

Creating link #5

Communication with all 5 active connections worked

Creating link #6

Communication with all 6 active connections worked

Creating link #7

Communication with all 7 active connections worked

Creating link #8

Communication with all 8 active connections worked

Creating link #9

Communication with all 9 active connections worked

Creating link #10

Communication with all 10 active connections worked

Creating link #11

Communication with all 11 active connections worked

Creating link #12

Communication with all 12 active connections worked

Creating link #13

Communication with all 13 active connections worked

Creating link #14

Communication with all 14 active connections worked

Creating link #15

Communication with all 15 active connections worked

Creating link #16

Communication with all 16 active connections worked

Creating link #17

Communication with all 17 active connections worked

Creating link #18

Communication with all 18 active connections worked

Creating link #19

Communication with all 19 active connections worked

Creating link #20

Communication with all 20 active connections worked

Creating link #21

Communication with all 21 active connections worked

Creating link #22

Communication with all 22 active connections worked

Creating link #23

Communication with all 23 active connections worked

Creating link #24

Communication with all 24 active connections worked

Creating link #25

Communication with all 25 active connections worked

Creating link #26

Communication with all 26 active connections worked

Creating link #27

Communication with all 27 active connections worked

Creating link #28

Communication with all 28 active connections worked

Creating link #29

link creation failed after 28 active connections

Maximum connection count reached: 28, we expected 27 simultaneous connections to work

Closing all connections

opening one connection again to see if GPIBee is stil responsive

Success! Query result: XYPHROLABS,GPIBEE,LJPAT,V1.5.2608231401

Summary: - test result: ✅ PASSED - duration: 1.921s

scan

Testcase description

Testing if the GPIB scan function works

Log

Using visa provider: pyvisa-py

Scan result: "22"

Summary: - test result: ✅ PASSED - duration: 0.089s

timeout_behavior_on_locked_link_with_no_wait_lock

Testcase description

Test if timeouts on locked devices is "close to zero" when no WAIT_LOCK is active

Note, that the measured values include additional overhead and is not a pure measurement of network call to reply time.

Log

Allowed timing inaccuracy: 600.0ms

Using visa provider: rs

Creating 1st link - used to lock and unlock instrument

Ensuring that instrument is not responding to reads

Creating 2nd link - used to measure lock timeout duration

Locking via 1st link the instrument (2nd link is already acquired)

Testing if a non WAIT_LOCK transaction on a locked link is returning "immediately"

Duration of read timeout: 1.004ms

Summary: - test result: ✅ PASSED - duration: 0.576s

timeout_extension_by_lock

Testcase description

Test if timeouts extend in time when a lock is active. iotimeout should only start counting once lock is acquired if WAIT_LOCK is 1. This testcases blocks with a lock for a defined time and then releaes it to see if this extension is visible.

Note, that the measured values include additional overhead and is not a pure measurement of network call to reply time.

Log

Allowed timing inaccuracy: 600.0ms

Using visa provider: rs

Creating 1st link - used to lock and unlock instrument

Ensuring that instrument is not responding to reads

Creating 2nd link - used to measure lock timeout duration

Locking via 1st link the instrument (2nd link is already acquired)

Starting IO timeout measurement

Testing timeout of 5000.0ms

[started exclusive locking in a seperate thread] Locking for 2 seconds

Kicked off read.

[stopped exclusive locking]

Testing timeout of 2000.0ms

[started exclusive locking in a seperate thread] Locking for 2 seconds

Kicked off read.

[stopped exclusive locking]

Testing timeout of 1000.0ms

[started exclusive locking in a seperate thread] Locking for 2 seconds

Kicked off read.

[stopped exclusive locking]

Lock duration [ms]	Requested io timeout duration [ms]	Expected overall timeout duration [ms]	Actual measured overall timeout duration [ms]	measured - Expected [ms]
2000.000	5000.000	7000.000	7118.497	118.497
2000.000	2000.000	4000.000	3970.012	-29.988
2000.000	1000.000	3000.000	3000.970	0.970

Summary: - test result: ✅ PASSED - duration: 14.686s

unsynchronized_simultaneous_access

Testcase description

Access GPIBee with multiple clients simultaneously in an asynchronous manner to see if any issues occur without locking. This requires a HP3457 to be present on GPIB address 22. Addresses https://github.com/xyphro/GpiBee/issues/33

Log

Creating link

Ensuring that instrument is in auto trigger mode

[started] Thread 0

[started] Thread 1

[started] Thread 2

[started] Thread 3

Thread 0 HP3457A

Thread 1 2.4181210E+00

Thread 2 2.4185260E+00

Thread 3 HP3457A

Thread 0 2.4182650E+00

Thread 1 2.4183580E+00

Thread 2 2.4182730E+00

Thread 3 HP3457A

Thread 0 2.4179380E+00

Thread 1 2.4178230E+00

Thread 2 2.4178170E+00

Thread 3 HP3457A

Thread 0 2.4175030E+00

Thread 1 2.4175770E+00

Thread 2 2.4174770E+00

Thread 3 HP3457A

Thread 0 2.4169550E+00

Thread 1 2.4169850E+00

Thread 2 2.4168540E+00

Thread 3 HP3457A

Thread 0 2.4161040E+00

Thread 1 2.4162460E+00

Thread 2 2.4164140E+00

Thread 3 HP3457A

Thread 0 2.4160120E+00

Thread 1 2.4160030E+00

Thread 2 2.4159310E+00

Thread 3 HP3457A

Thread 0 2.4153660E+00

Thread 1 2.4153460E+00

Thread 2 2.4152950E+00

Thread 3 HP3457A

Thread 0 2.4147510E+00

Thread 1 2.4146660E+00

Thread 2 2.4146430E+00

Thread 3 HP3457A

Thread 0 2.4141840E+00

Thread 1 2.4141710E+00

Thread 2 2.4141270E+00

Thread 3 HP3457A

Thread 0 2.4130850E+00

Thread 1 2.4128990E+00

Thread 2 2.4134360E+00

Thread 3 HP3457A

Thread 0 2.4127280E+00

Thread 1 2.4126050E+00

Thread 2 2.4127320E+00

Thread 3 HP3457A

[stopped] Thread 3

Thread 0 2.4119290E+00

[stopped] Thread 0

Thread 1 2.4119380E+00

[stopped] Thread 1

Thread 2 2.4119680E+00

[stopped] Thread 2

Summary: - test result: ✅ PASSED - duration: 5.449s
